Technical data 1 7712 11

• Operation time 60 / 120 s

• Stroke 8 mm

• Pushing force 500 N

• Weight 0,7 kg

• Max. operating temperature 100 °C on valve body

• Ambient temperature -10 to 55 °C

• Ambient humidity 5 to 95% r.F.

• Electrical protection IP 54 (EN 60529)

• Control signal 0 to 10 V, Rj >100 kOhm

• Positional feedback signal 0 to 10 V, load > 10 kOhm

• Starting point U0 0 to 10 V

• Power consumption 60 s 120 s

• Response time 200 ms

Technical data 1 7712 50/51

• Operation time 120 s

• Stroke 8 mm

• Pushing force 500 N

• Weight 0,7 kg

• Max. operating temperature 100 °C on valve body

• Ambient temperature -10 to 55 °C

• Ambient humidity 5 to 95% r.F.

• Electrical protection IP 54 (EN 60529)

• Power consumption 120 s

• Response time 100 ms
